Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| SF CIRCULAR 350 S 18 W 3000 K IP44 WT | 18.00 W | 50000 | 120 ° | 1440 lm | No |
| SF CIRCULAR 350 S 18 W 4000 K IP44 WT | 18.00 W | 50000 | 120 ° | 1440 lm | No |
| SF CIRCULAR 350 S 18 W 4000 K IP44 WT | 18.00 W | 50000 | 120 ° | 1440 lm | No |
| Nominal wattage | 18.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 153 mA |
| Inrush current | 15.0 A |
| Inrush current time Th50 | 200 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 31 |
| Max. number of luminaires per miniature circuit breaker C10 | 26 |
| Max. number of luminaires per miniature circuit breaker C16 | 42 |
| Power factor λ | ≥0.5 |
| Total harmonic distortion | < 120 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 1440 lm |
| Luminous efficacy | 80 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 5 sdcm |
| Low flicker | Yes |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 120 ° |
| Diameter | 350.00 mm |
| Height | 115.00 mm |
| Product weight | 655.00 g |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polymethylmethacrylate (PMMA) |
| Light emitting surface material | PMMA |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -25…+70 °C |
| Type of connection | Screw terminal, 3-Pole |
| Type of protection | IP44 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling, Wall |
| Application environment | Indoor |
| Replaceable light source | No |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Lifespan L80/B10 at 25 °C | 22000 h 1) |
| Lifespan L90/B10 at 25 °C | 15000 h |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 117 mA |
| Type of sensor | Motion, Light |
| Sensor technology | Microwave |
| Sensor detection angle | 110 ° |
| Sensor controlled switching time | 5 s/1 min/3 min/10 min |
| Detection range of motion sensor | 8 m |
| Detection threshold of daylight sensor | 25 lx |
| Sensor IP rating | IP44 |
| Standards | CE, CB, TÜV SÜD, EAC, RoHS |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075110229 | Folding box 1 |
386 mm x 386 mm x 120 mm | 1024.00 g | 17.88 dm³ |
| 4058075110236 | Shipping box 5 |
625 mm x 410 mm x 410 mm | 6137.00 g | 105.06 dm³ |
| EAN | SEG number | STK number | EFO number |
|---|---|---|---|
| 4058075110229 | 7504780 | 4125320 | 3201935 |
