Choose your product version
| Nominal voltage | 220…240 V |
| Type of current | AC |
| Mains frequency | 50…60 Hz |
| Surge capability (L-N) | 1 kV |
| Length | 76.00 mm |
| Width | 61.50 mm |
| Height | 76.00 mm |
| Product weight | 82.2 g |
| Product color | White |
| Ambient temperature range | -20…+45 °C |
| Dimmable | No |
| Maximum installation height | 2.2…4 m |
| Detection area | 6 m 1) |
| Detection angle | 360 ° |
1) Maximum diameter
| Protection class | II |
| Type of protection | IP20 |
| Temperature range at storage | -35…+55 °C |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075383258 | Folding box 1 |
80 mm x 80 mm x 86 mm | 108.00 g | 0.55 dm³ |
| 4058075383265 | Shipping box 10 |
412 mm x 172 mm x 108 mm | 1270.00 g | 7.65 dm³ |
| EAN | AU model number |
|---|---|
| 4058075383258 | LDVSENSORPIRCR360 |
