Choose your product version
| Product description |
|---|
| LM-SV 100-RED-DC 24W 24V IP20 |
| LM-SV 100-BLU-DC 24W 24V IP20 |
| Nominal wattage | 24.00 W |
| Construction wattage | 24.00 W |
| Nominal wattage per meter | 4,8 W |
| Nominal voltage | 24 V |
| Type of current | DC |
| Luminous efficacy | 40 lm/W |
| Luminous flux per meter | 180 lm |
| Light color (designation) | Red |
| Beam angle | 120 ° |
| Number of LEDs per meter | 60 |
| Length | 5000.00 mm |
| Length – smallest unit | 100 mm |
| Width | 8.00 mm |
| Height | 1.50 mm |
| Product weight | 120.00 g |
| Ambient temperature range | -20…+45 °C |
| Maximum temperature at tc test point | 75 °C |
| Nominal lamp life time | 40000 h |
| Number of switching cycles | 100000 |
| Dimmable | No |
| Lowest bending radius | 30 mm |
| Self-adhesive | Yes |
| Type of protection | IP20 |
| Temperature range at storage | -20…+80 °C |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075359864 | BAG 1 |
157.00 g | ||
| 4058075359871 | Shipping box 10 |
188 mm x 153 mm x 211 mm | 1684.00 g | 6.07 dm³ |
| 4058075359888 | Shipping box 40 |
402 mm x 328 mm x 238 mm | 7334.00 g | 31.38 dm³ |
