| Nominal wattage | 20 W |
| Construction wattage | 20.00 W |
| Nominal voltage | 12 V |
| Power factor λ | 1.00 |
| Luminous flux | 300 lm |
| Luminous efficacy | 15 lm/W |
| Light color (designation) | Warm White |
| Color temperature | 2800 K |
| Color rendering index Ra | 100 |
| Light color | 1028 |
| UV protection | Yes |
| Starting time | 0 s |
| Overall length | 33.00 mm |
| Light center length (LCL) | 22,0 mm |
| Diameter | 10,0 mm |
| Product weight | 1.12 g |
| Base (standard designation) | G4 |
| Mercury-free | Yes |
| Product remark | Heat-resistant up to 300 °C, Lamp suitable for oven with high temperature self cleaning (Lamps must be switched off! Max. ambient temperature 450 °C), For use in shielded luminaires only |
| Dimmable | Yes |
| Burning position | Any |
| Energy efficiency class | G |
| Energy consumption | 20.00 kWh/1000h |
| ILCOS | HSGST/C/UB-20-12-G4-10/22 |
| Order reference | 64428 OVEN 20W |
| Lighting technology used | OTHER |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | G4 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 33.00 mm |
| Height | 10,0 mm |
| Width | 10,0 mm |
| Chromaticity coordinate x | 0.452 |
| Chromaticity coordinate y | 0.409 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 714455 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300023946 | Folding box 400 |
148 mm x 136 mm x 66 mm | 491.00 g | 1.33 dm³ |
| 4050300256917 | Shipping box 3,200 |
310 mm x 150 mm x 285 mm | 4680.00 g | 13.25 dm³ |
